LED

Total LEDs 1,224.

Lumens 5130.

Exposure  24fps 1/48sec  800asa @ 100% 2’ /61cm - f22.7   |    4’ / 122cm - f11.4   |   16’  /  488cm - f4.0.3.

Color range 2600K to 6000K.

Dimming range 0 – 100%.

Color rating 98++ CRI.

HEAD

Head size open - parabolic 22.5”/57.15cm ø hex  x  7.5”/19.05cm parabola.

Head size open - flat 29”/73.66cm ø hex  x  1”/2.5cm.

Configurations Parabolic, flat and folded.

Head size closed 8”/20.32cm  x  6” /15.24 CM ø octa.

Head weight 3lbs 4oz / 1.47kgs.

Materials 7071+6065 Aluminum, stainless steel and silicone plastics.

ELECTRONICS

3 BALLAST OPTIONS 400w LiteDimmer, 200w LiteDimmer or 250w DC LiteDimmer.

DATA(LiteDimmer option)

DMX connector Input/output 5 pin XLR connector.

Service port USB Type A – service center upgradeable..

Data protocol DMX 512A.

Wireless Built in LumenRadio.

RIGGING

Mounting point 3/8” Thread front and back.

Baby pin 3/8” Thread, 5/8” ø x 3.5”/8.9cm.

Mounting method Install baby pin to the front or back thread for a 5/8” grip head.

FABRICS

Diffusions 22.5” /57.15cm ø octagon x varied fabris.

Utility backing cover Poly and nylon fabrics stitched, reinforced and laminated.

CASE

Case type Injection molded waterproof case and custom foam cut insert by SKB.

Case size 20” x 20” x 11” / 50.8cm x 50.8cm x 27.9cm.

Case weight - packed 30lbs / 13.6 kgs.
