LED
Total LEDs 3,456.
Lumens 15280.
Exposure 24fps 1/48sec 800asa @ 100% 3’ / 91cm - f22.2 | 6’ / 182cm - f11.5 | 9’ / 273cm - f8.4.
Color range 2600K to 6500K.
Dimming range 0 – 100%.
Color rating 98++ CRI.
HEAD
Head size open - parabolic 37”/95.2cm ø octa x 15.5” /39.4cm Parabola.
Head size open - flat 50”/127cm ø octa x 1”/2.5cm.
Configurations Parabolic, flat and folded.
Head size closed 12”/30.5cm x 8” /20.3 CM ø octa.
Head weight 7lbs 4oz / 3.3kgs.
Materials 7071+6065 Aluminum, steel and silicone plastics.
ELECTRONICS
Output voltage 24 VDC Constant voltage.
Input voltage 90 – 305V AC, 50/60hz (C14 connector) Universal.
Power 400W.
Power connectors 7 PIN Bayonet locking system PWM (PL7 connector) IP 68.
Ballast Protection Over current/voltage/temperature or short circuit.
Ballast IP rating IP20.
Ballast size 14”/35cm L x 5”/12.7cm H x 7”/17.8cm W.
Ballast weight 11lbs 11oz / 5.3kg.
Head feeder length 24’ / 7.3m.
IEC cord set US.
DATA
DMX connector Input/output 5 pin XLR connector.
Service port USB Type A – service center up-gradeable.
Data protocol DMX 512.
RIGGING
Mounting point 3/8” Thread front and back.
Baby pin 3/8” Thread, 5/8” ø x 3.5”/8.9cm.
Mounting method Install baby pin to front or back for a 5/8” grip head.
FABRICS
Diffusions 36” / 91.4cm ø octagon x varied fabric.
Utility backing cover Poly and nylon fabrics stitched, reinforced and laminated.
CASE
Case type Injection molded waterproof case with foam cut insert.
Case size 12.5” x 21” x 24” / 31.75cm x 53cm x 70cm.
Case weight - packed 49lbs / 22.2 kgs.
LED
Total LEDs 1,224.
Lumens 5130.
Exposure 24fps 1/48sec 800asa @ 100% 2’ /61cm - f22.7 | 4’ / 122cm - f11.4 | 16’ / 488cm - f4.0.3.
Color range 2600K to 6000K.
Dimming range 0 – 100%.
Color rating 98++ CRI.
HEAD
Head size open - parabolic 22.5”/57.15cm ø hex x 7.5”/19.05cm parabola.
Head size open - flat 29”/73.66cm ø hex x 1”/2.5cm.
Configurations Parabolic, flat and folded.
Head size closed 8”/20.32cm x 6” /15.24 CM ø octa.
Head weight 3lbs 4oz / 1.47kgs.
Materials 7071+6065 Aluminum, stainless steel and silicone plastics.
ELECTRONICS
3 BALLAST OPTIONS 400w LiteDimmer, 200w LiteDimmer or 250w DC LiteDimmer.
DATA(LiteDimmer option)
DMX connector Input/output 5 pin XLR connector.
Service port USB Type A – service center upgradeable..
Data protocol DMX 512A.
Wireless Built in LumenRadio.
RIGGING
Mounting point 3/8” Thread front and back.
Baby pin 3/8” Thread, 5/8” ø x 3.5”/8.9cm.
Mounting method Install baby pin to the front or back thread for a 5/8” grip head.
FABRICS
Diffusions 22.5” /57.15cm ø octagon x varied fabris.
Utility backing cover Poly and nylon fabrics stitched, reinforced and laminated.
CASE
Case type Injection molded waterproof case and custom foam cut insert by SKB.
Case size 20” x 20” x 11” / 50.8cm x 50.8cm x 27.9cm.
Case weight - packed 30lbs / 13.6 kgs.
